| MOQ: | 2 pieces |
| Price: | negotiate |
| Standard Packaging: | Wooden box |
| Delivery Period: | 7-15 days |
| Payment Method: | L/C, D/A, D/P, T/T, MoneyGram |
| Supply Capacity: | 4000 Piece/Pieces per Week |
| Product Model: | ESK-4810CW | ESK-4820CWP | ESK-4820CW |
| Type of Battery: | Lithium Iron Phosphate | ||
| Max parallel: | 16 sets | ||
| Rated capacity: | 100AH (5120WH) | 184AH (9420.8WH) | 200AH (10240WH) |
| Rated voltage : | 51.2V | ||
| Charging voltage: | 58.4V | ||
| Max charging current | 100A | ||
| Max continuous discharge current: | 100A/150A/200A optional | ||
| Weight: | 47kg | 74kg | 85kg |
| Dimension (L* W * H) mm: | 620*460*195 | 850*455*180 | 955*460*195 |
| Display: | LCD | ||
| Warranty : | 8 years | ||
| communication function: | CAN/RS485/RS232 | ||
| Shell Material | White painted steel | ||
| Cycle life | ≥6000 times | ≥8000 times | ≥8000 times |
| Operating temperature | -20℃ to +65℃ | ||
| Protection function | Overcharge protection, over discharge protection, over-current protection, short circult protection, over temperature protection and low voltage alarm | ||
| Matched solar inverter brands | PYLONTECH/GOODWE/Growatt/SMA/Victron/TBB/Must/Srne/MEGAREVO/Deye/INVT/Voltronic/SOFAR/SOROTEC,etc. | ||
| Bluetooth function | Optional | ||
| Application | Home Appliances, Industrial and commercial energy storage,Household energy storage,Large-scale photovoltaic energy storage projects,UPS energy storage | ||
Main features
●Support OEM services
●Wall mounted design, firm and safe structure
●24V ,48V LiFePO4 pack ,Safe and reliable
●Built-in intelligent BMS system to balance all cells ,matching solar panel and solar inverter
●Built-in automatic protection can prevent overcharge, overdischarge, overvoltage, short circuit and over
temperature
●With RS485/RS232/CAN communication functions (WiFi/Bluetooth optional).
●Matching solar panel and solar inverter
●Cycle life≥8000 times 80% DOD
●＞5 years warranty,the design life is 20 years
●LCD display showing the working data
●UL94V-0 flame retardant system, good high temperature performance
●Excellent standby power consumption is 4mA and can automatically enter sleep
●With equalization module, all-round protection and unattended operation
Wall mounted & floor standing In tegrated Design suitable for various household use scenarios,
You can hang the battery on the wall or place it on the floor
Grade A lifepo4 blade cell Built-in intelligent BMS system
＞8000 cycle life Grade A lifepo4 blade Intelligent BMS balancing module ensures the stability
cell for higher and safer temperature resistance. and balance of all battery cells.
1.OEM/ODM customization service
We can customize your exclusive energy storage products and system according to your needs, and display or provide them to you to confirm whether they meet your needs.
2.Global service
Our products have been exported to more than 40 countries and regions. A professional pre-sales and
3.R & D team
We have more than 10 senior engineers and more than 60 professional technicians who have been
committed to product R & D for more than 18 years
4.Quality control
Quality control is the basis of our management. We put it first. All products are strictly tested before leaving
the factory
5.Source factory
All products are developed and produced by ourselves, with guaranteed quality and service and preferential prices.
6. Professional pre-sales and after-sales team
We have a professional pre-sales and after-sales team to serve you. The pre-sales team can ensure that
we can accurately understand your needs, accurately convey your needs to the factory, and supervise the
factory to accurately produce the products you need. The after-sales team can conduct installation teaching and use technical guidance after you receive the product, and can track and solve any problems for you in time when the product has any problem
|
|
